Linear Magnetic Hall Effect Sensor Module

Hall Effect Sensor Module is used to Detect the proximity of a magnet. It is very much Smaller in size. When the magnetic field rises above a threshold level, the open-collector output transistor switches on, which pulls the logic-compatible output low and illuminates the on board LED indicator.

Its fast (The turn-on threshold is 35-450 Gauss, the minimum hysteresis is 20 Gauss, and the operating voltage range is 4.5 - 24 volts. This module uses the Allegro Microsystems A3144EUA sensor. It has a 3 pin interface, signal, V+ and GND.

To use this sensor/switch, place a 10K pull-up resistor between the "S" pin and the middle pin (+), connect the "-" pin to ground. Supply voltage to the middle pin. The "S" pin will go low (gets pulled to ground) and the on board LED indicator will turn on when a magnet is brought near.

A magnetic field is detected by the sensor and will be printed as an analog voltage value. You can control the sensitivity of the sensor with the potentiometer.

Features :

Features wide range voltage comparator LM393
Adjustable sensitivity
Signal output indicator with the retaining bolt hole, convenient installation
Output form digital switch output (0 and 1 high and low level)
Signal output indication
Single channel signal output
The output effective signal is low level
When there is sound, outputs low level and the signal light
Can be used for Acoustic control light, give sound and light alarm working with the Photosensitive sensor, and sound control, sound detect

Specifications:

Operating Voltage(VDC)	3.3 to 5
Length (mm)	35
Width (mm)	15
Height (mm)	14
Weight (gm)	3

Pins:

VCC ↔ 2.3V ~ 5.3V
GND ↔ power supply ground
AOUT ↔ MCU.IO (analog output)
DOUT ↔ MCU.IO (digital output)

Applications

Motor speed measurement
Object position detection
Smart car
Electronic bricks

Package Includes :

1 x Linear Magnetic Hall sensor
